Flush Panel Metal Siding

Available in Both Flat and Vented Panels

This slideshow requires JavaScript.

Flush Panel metal siding is ideal for wall, soffit, fascia, and mechanical screen applications as they have a low profile. This product is a concealed fastened panel available in flat and vented options, which provide a distinct design for any project. Flush Panel is an excellent metal profile for civic, commercial, retail, and other institutional projects.

With this long-lasting, durable, and sustainable metal panel, you’ll find it also comes in several energy-efficient colors and paint systems. Flush Panel offers architects and building owners a unique yet flexible design when the product is installed in a vertical or horizontal pattern or combined with other building materials.

AEP-Guide-Large-HomeWall assemblies are rated for fire resistance (UL263) when installed in accordance with UL listings.



Get Inspired!

Download the AEP Span Product Selection Guide and Color Design Guide.

  • 12″ coverage wall panel.
  • Wall Installation: Horizontal or Vertical
  • Gauges: Available in standard 24ga for soffit or fascia applications and 22ga for wall applications.
  • Refer to AEP Span Color Charts (pdf) (rtf) for full range of color options and paint systems.
  • Custom manufactured panel lengths: 5′-0″ to 30′-0″ (22ga) 5′-0″ to 25′-0″ (24ga).
  • Factory applied sealant is not available.
  • Available with 1 or 2 pencil ribs.
  • Venting available. Pencil ribs required for vented panel. Venting is 11.23 in2/ft2 open area.
  • ASTM E1592 (wind uplift), ASTM E283* (air infiltration) and ASTM E331* (water infiltration) tested. All testing performed by accredited third-party. * Requires field applied sealant.
  • Wall assemblies rated for fire resistance (UL263) when installed in accordance with UL listings.
  • Oil Canning: All flat metal surfaces can display waviness commonly referred to as “oil canning”. “Oil canning” is an inherent characteristic of steel products, not a defect, and therefore is not a cause for panel rejection. Oil Canning Technical Bulletin (pdf) (rtf)
  • Manufactured in Tacoma, WA.

Dura Tech™ 5000 and Dura Tech™ mx

  • Architectural Color Chart: Dura Tech 5000 & mx (pdf) (rtf)
  • Dura Tech™ 5000/Dura Tech® mx Warranty (PVDF) (pdf) (rtf)

Dura Tech™ nt

Design and Color Solutions
Specialty Prints, Textures & Finishes

ZINCALUME® Plus

  1. Flush Panel Horizontal Installation

  2. Flush Panel Vertical Installation
