SpanSeam™ metal roofing is a 16″ wide mechanically seamed concealed fastener roofing panel with a narrow 2″ high rib. The weather-tight design and modern aesthetics make it ideal for commercial and architectural roofing applications. The panel is available as a flat pan or striated option. For narrow applications, please inquire with your AEP Span sales representative for details about our On-Site Roll Former.
Product Information
Product Details
Documents & Resources
BIM/CAD Data
Warranty Information
Product Details
- Panel Type: Concealed fastener metal roofing (standing seam)
- Standard Base Metal: Zincalume® Steel (AZ50)
- Coverage: 16″
- Metal Thickness (Gauge): 24, 22
- Minimum Slope: 1⁄4:12
- Orientation: Vertical
- Paint System: Dura Tech™ 5000 / Dura Tech™ mx (PVDF – 24, 22ga)
- Panel Attachment: Mechanically Seamed with Concealed Clips
- Performance Certification: UL 580 (Class 90 Wind Uplift), UL 790 (Class A Fire Rated), ASTM E1592 (Wind Uplift), ASTM E1680 (Air infiltration), ASTM E1646 and E2140 (Water Infiltration), UL2218 (Class 4 Impact Resistance – Hail), ER 309 Building Code Evaluation Report
- Panel Height: 2″
- Rib Style: Standing Seam
- Primary Application: Commercial and Architectural Roofing
- Standard Configuration: Striated
- Factory Applied Sealant: Yes
- Optional Configuration: 2 Pencil Ribs, Flat Pan
- Available Panel Lengths: 6′-0″ to 45′-0″
- Other Options (inquire): Factory Notching, Factory Swaged
Documents & Resources
Product Resources
- Span Seam™ Product Sheet with Load Tables (pdf)
- Span Seam™ Panel Dimensions (pdf)
- Span Seam™ Installation Guide (pdf)
- Concealed Fastener Steel Roof and Wall Panel Structural Design Guide (pdf)
- Span Seam™ Guide Specifications (pdf) (doc)
- Building Code Approval Report (Evaluation Report ER-0309)
Product Option and Accessory Resources
Color Resources
- Architectural Color Chart (Dura Tech™ 5000/mx) (pdf | rtf)
- Commercial Color Chart (Dura Tech™ nt) (pdf | rtf)
- Color Performance Data (SRI and LRV Values) (pdf)
Sustainability Resources
BIM/CAD Data
Warranty Information
- Finish Warranty PVDF Paint System – Dura Tech™ 5000 & Dura Tech™ mx Warranty (pdf)
- Corrosion Warranty – ZINCALUME® Plus Warranty (pdf)
- Full System Weathertight Warranty Available By Request (Sample Warranty | Inquire)
- Side Seam Weathertight Warranty Available By Request (Sample Warranty | Inquire)
Product Details
- Panel Type: Concealed fastener metal roofing (standing seam)
- Standard Base Metal: Zincalume® Steel (AZ50)
- Coverage: 16″
- Metal Thickness (Gauge): 24, 22
- Minimum Slope: 1⁄4:12
- Orientation: Vertical
- Paint System: Dura Tech™ 5000 / Dura Tech™ mx (PVDF – 24, 22ga)
- Panel Attachment: Mechanically Seamed with Concealed Clips
- Performance Certification: UL 580 (Class 90 Wind Uplift), UL 790 (Class A Fire Rated), ASTM E1592 (Wind Uplift), ASTM E1680 (Air infiltration), ASTM E1646 and E2140 (Water Infiltration), UL2218 (Class 4 Impact Resistance – Hail), ER 309 Building Code Evaluation Report
- Panel Height: 2″
- Rib Style: Standing Seam
- Primary Application: Commercial and Architectural Roofing
- Standard Configuration: Striated
- Factory Applied Sealant: Yes
- Optional Configuration: 2 Pencil Ribs, Flat Pan
- Available Panel Lengths: 6′-0″ to 45′-0″
- Other Options (inquire): Factory Notching, Factory Swaged
Documents & Resources
Product Resources
- Span Seam™ Product Sheet with Load Tables (pdf)
- Span Seam™ Panel Dimensions (pdf)
- Span Seam™ Installation Guide (pdf)
- Concealed Fastener Steel Roof and Wall Panel Structural Design Guide (pdf)
- Span Seam™ Guide Specifications (pdf) (doc)
- Building Code Approval Report (Evaluation Report ER-0309)
Product Option and Accessory Resources
Color Resources
- Architectural Color Chart (Dura Tech™ 5000/mx) (pdf | rtf)
- Commercial Color Chart (Dura Tech™ nt) (pdf | rtf)
- Color Performance Data (SRI and LRV Values) (pdf)
Sustainability Resources
BIM Data
Warranty Information
- Finish Warranty PVDF Paint System – Dura Tech™ 5000 & Dura Tech™ mx Warranty (pdf)
- Corrosion Warranty – ZINCALUME® Plus Warranty (pdf)
- Full System Weathertight Warranty Available By Request (Sample Warranty | Inquire)
- Side Seam Weathertight Warranty Available By Request (Sample Warranty | Inquire)
Colors
Cool DURA TECH™ 5000 (22 & 24 Gauge)
Architectural standard colors in our premium 70% fluoropolymer (PVDF) paint system.
Cool DURA TECH™ mx (22 & 24 Gauge)
Metallic standard colors in our premium 70% fluoropolymer (PVDF) pearlescent paint system.
Cool DURA TECH™ nt (26 Gauge)
Standard commercial colors in our premium silicone-modified polyester (SMP) paint system.
No available colors in this category.
Premium Colors (24 & 26 Gauge)
Unpainted Products (26 - 20 Gauge)
Uncoated and Unpainted Products (22 Gauge)
No available colors in this category.
Specialty Finishes and Custom Colors
AEP Span’s non-standard Specialty Finishes Catalog showcases an extensive range of innovative and high-quality metal finishes to meet the most discerning architectural design needs. This catalog also provides detailed specifications and performance data to aid in the finish selection and specification process.
